Z-800.1D

Features:
·  1 Ohm load stable.
·  Double side FR-4 PCB,high quality SMD components.
·  Full MOSFET circuit design.
·  Adjustable subsonic filter(Z-800.1D only).
·  Adjustable low pass filter.
·  Adjustable bass boost level.
·  Adjustable phase control(Z-800.1D only).
·  Adjustable gain control.
·  Overload,short circuit,thermal,low voltage protection.
·  Remote bass level control(with remote bass knob).

Basic Info

 RMS @ 1 Ohm 756 W
 RMS @ 2 Ohm 496 W
 RMS @ 4 Ohm 289 W
  Frequency Response 15Hz - 250Hz
  S/N Ratio >80 dB
  THD  ≤0.5%
  Input Sensitivity Level 0.2V - 6V
  LPF 50Hz - 250Hz
  Subsonic Filter  10Hz - 50Hz
  Dimension(L×W×H) 231×120.5×48 mm
