HT-5000
Features：
· 1 Ohm load stable.
· Double side FR-4 PCB, high quality SMD components.
· Full range MOSFET circuit design.
· Adjustable low pass filter.
· Adjustable High pass filter.
· Adjustable bass boost frequency and level.
· Overload, thermal, low voltage protection.
· Remote level control.
Basic Info
| RMS @ 1 Ohm | 5000W |
| RMS @ 2 Ohm | 2964W |
| RMS @ 4 Ohm | 1681W |
| Frequency Response | 20Hz ~ 20kHz |
| S/N Ratio | >50 dB |
| THD | ≦0.5% |
| Input Sensitivity Level | 0.2V ~ 6V |
| LPF | 80Hz ~ 20kHz |
| HPF | 15Hz ~ 80Hz |
| Bass Boost Level | 0dB ~ 12dB |
| Dimension(L×W×H) | 265×228×68 mm |
