FX-10D2
FX-10D2 10"Subwoofer
.(400 Watts RMS Sealed Enclosure)
.10”custom tooled high efficiency non pressed paper cone with foam surround
.Dual 2 premium high temperature voice coil
.800 Watts Peak/400 Watts RMS
. Frequency Response:25 Hz-2k Hz
.Sensitivity:85 dB(1 Watt/1 Meter)
. Impedance:Dual 2 Ohm
.Mounting Depth:6.10 Inch(155 mm)
Basic Info
|
FX-10D2 Speaker Impedance |
table |
1 ohms |
4 ohms |
|
Free Air Resonance |
Fs |
34 |
35 |
|
Total Q Driver @ Fs including all resistance% |
Qts |
0.410 |
0.461 |
|
Q of the Driver@ Fs including non electronical resistance only |
Qms |
8.400 |
8.367 |
|
Q of the Driver @Fs including electronical resistance only |
Qes |
0.500 | 0.488 |
|
The Driver% compliance expressed as an equivalent |
Vas |
24.77L | 24.77L |
|
Volume of all (cubic Ft) |
|
||
|
The Driver%s linear displacement (inches) |
Xmax | 0.31 | 0.31 |
|
The Dc resistance of the driver% twin voice coils &ohms |
Re | 1.0 | 4.0 |
|
Thermal Power rating of the Driver(RMS/Peak) |
Pe |
400W/800W |
400W/800W |
|
The Driver% sensitivity(dB) |
Sens |
85 |
85 |
